Lektro AP8850SDA – Electric Towbarless Aircraft Tug

P/N: AP8850SDA

Vehicle Drive: 45.3 HP/33.8 kW, 72 VDC Traction Motor mated with Auburn/Dana 44 Differential.
Motor Speed Control: EV-200 LX SCR with On-Board Diagnostics. Speed controlled by Foot Throttle.
Batteries: Two 36 VDC Industrial, 440 AMP-HR Batteries (6 hr rate), wired in series.
Motive Battery Charger: External Fully Automatic 90 AMP DC / 208-480 VAC / 60 Hz / 1-PH Charger. 50 Hz, 3-PH, and/or 100 AMP, optional.
Nose Gear Lift Cradle: Patented Universal Nose Gear Lift Cradle activated by an Electric/Hydraulic Pump Assembly capable of handling dual and single wheel aircraft, and a Hold Down provision for lightnosed aircraft.
Winch: Heavy-duty Hydraulic Winch with Automatic Safety Cut-Off. Winch and Strut Straps included.
Steering: Electric/Hydraulic Power Steering controlled through Automotive-type Tilt Wheel requiring minimal effort with very responsive steering action. Automatic Timer turns off power when tug not in use, increasing battery shift life.
Service Brakes: Foot Operated Hydraulic Disc-Type Service Brakes utilizing the final Wheel Drive Gearing to achieve maximum braking with minimal effort
Parking Brake: Hand activated Electric Switch controlling Spring Applied/Hydraulic Released Calipers mounted on each Service Brake Disc. Drive Tires: 23 x 10 x 12 18-ply Pneumatic Traction Tread with Siping. Solid-Pneumatic Tires and Chains, optional. Steer Tires: 21 x 8-9 Solid-Pneumatic Traction Tread mounted to a Fully Suspended Steer Axle.
Lighting: Dual Forward and Aft Headlights, Four Flashing Amber Running Lights and Amber Strobe Light mounted Center Rear.
Operator’s Compartment: Operator and Passenger Seats, Forward Facing, Premium Grade, Molded Polyurethane including Armrests. Operator’s Seat features a Fully Suspended, Adjustable setting for height, fore/aft and weight.
Construction: Welded Steel Plate and Polymers preserved by Primer and Automotive High-Gloss Red or White Enamel Paint with special protective Polyurethane Coating to prevent rust, scratches and corrosion.

Lektro AP8850SDA - Electric Towbarless Aircraft Tug

Lektro AP8850SDA - Electric Towbarless Aircraft Tug - Image 2

Additional Information
Shipping

Description

LEKTRO 88 tow tractors can move aircraft with an MTOW up to 120,000 lbs (54,432 kg), making them ideal for pushbacks and towing regional jets and turboprop aircraft. They are also extremely versatile for being able to tow a wide range of business aircraft and are popular units for busy FBO corporate flight departments worldwide. Aircraft nose gear is secured using a soft strap and cradle system, which eliminates tow bars, is simple to maintain, and helps avoid the complexity that may come with the capture systems on many other towbarless tractors. Electric power and a tight turning radius make the LEKTRO 88 the ideal tow tractor for moving just about any aircraft in its weight capacity.
