Tronair 02A7844C0111 – 30-Ton Aircraft Hydraulic Tripod Jack with Air Pump (CE)

P/N: 02A7844C0111

The Tronair 02A7844C0111 is a 30-ton, single-stage aircraft hydraulic tripod jack that comes preinstalled with an air pump. The jack is designed for use on select Boeing, Bombardier (Business), Gulfstream, and McDonnell Douglas aircraft.

Submit A Request

Tronair 02A7844C0111 – 30-Ton Aircraft Hydraulic Tripod Jack with Air Pump (CE)

Tronair 02A7844C0111 – 30-Ton Aircraft Hydraulic Tripod Jack with Air Pump (CE) - Image 2

Additional Information
Shipping

Description

Hand pump with factory preset built-in pressure relief valve
Air pump on all models with an “A” as the third digit of the model number (e.g. 02A1036-0111)
CE Approved Models have a “C” as the eighth digit, (e.g. 02-0517C0140)
Threaded rams with improved hand wheel style safety nut (except on 02-0222C0111 and 02-0234-0111 jacks)
Quick rising center extension (except on 2, 25 and 30 ton jacks)
Easy access filler/breather cap
Spherical radius cup jack pads
Heavy duty wheels on all jacks where spring loaded casters are not standard
Hydraulic fluid: MIL-PRF-5606
Finish: Durable Powder Coat Tronair Blue

Additional information

Weight	500 lbs
Specifications	Rated Capacity: 60,000 lbs. (27.2 metric tons) Closed Height: 46" (117 cm) Hydraulic Extension: 27" (69 cm) Mechanical Extension: 16" (41 cm) Fully Extended Height: 89" (226 cm) Weight: 500 lbs. (227 kg)
